Product Center
Applications ·Motor Drivers ·AC and DC servo drive amplifier ·UPS (Uninterruptible Power Supplies) Features ·Low switching losses ·Low vce(sat) with positive temperature coefficient ·Including fast & soft recovery anti-parallel FWD ·Low inductance case ·High short circuit capability(10us) ·Maximum junction temperature 175℃
Applications ·High frequency drivers ·Solar inverters ·UPS (Uninterruptible Power Supplies) ·Electric welding machine Features ·High speed IGBT in NPT technology ·Low switching losses ·High short circuit capability(10us) ·Including ultra fast & soft recovery anti-parallel FWD ·Low inductance ·Maximum junction temperature 150℃
Features ●VR 75V ●IFAV 150mA Typical Applications ● Extreme fast switches Mechanical Data ● Package: SOD123 ● Terminals: Tin plated leads, solderable per J-STD-002 and JESD22-B102 ● Polarity: Cathode line denotes the cathode end ● Marking: T4
1、BST耐压超过600V；2、脚位兼容IR2101；3、上下通道输出延时匹配；4、兼容3.3V、5V、15V 逻辑输入；5、内置死区时间防止上下通道直通。
1.集成1颗高可靠性HVIC，2颗2.4ohm,2A/500V快恢复MOSFET；2.DIP8小体积，低成本封装；3. >10us 短路电流耐固能力；4. 集成保护特性： - Shoot-through保护 - VCC&BST-SW UVLO保护检测 - 过温度保护。
